Amprobe ACDC-100 1000A AC/DC Clamp Meter

Amprobe ACDC-100 1000A AC/DC Clamp Meter

  • Large, easy to read LCD display
  • Auto and manual ranging
  • Relative zero mode
  • Auto power off
  • Data hold
  • MAX capture function for inrush current measurements (30 mS response)
  • Diode test
  • Audible continuity
  • Accommodates conductors up to 2.00 (50mm) in diameter
  • “Third hand” – test probe holder
  • Rubber over-molded case with built-in probes storage
  • Carrying case, test leads, batteries (installed) and user manual included



SKU: 2740452 Category:

Product Highlights

Where accuracy, quality, and newest technology meet. The ACDC-100 offers superior AC/DC measurement capabilities, highest product quality and enhanced ergonomics with red, rubber, Ribs™ design. The true-rms version addresses needs of professionals who rely on performance and reliability.

Specifications

FEATURE ACDC-100 ACDC-100 TRMS
True-rms
AC Current 400.0 A, 800 A
DC Current 400.0 A, 1000 A
Voltage AC/DC 400.0 mV, 4.000 V, 40.00 V, 400.0 V, 600 V
Resistance 400.0 O, 4.000 kO, 40.00 kO, 400.0 kO, 4.000 MO, 40.00 MO
Continuity
Capacitance 500.0 nF, 5.000 µF, 50.00 µF, 500.0 µF, 3000 µF
Accommodates conductors up to 2.0 (50 mm) in diameter
Specifications
True-rms: N/A
DC Current: 400.0 / 1000 A Accuracy: +/-(1.5% Rdg + 4 LSD) @ 0 to 800A **
AC Current: 400.0 / 800 A Accuracy: +/-(1.5% Rdg + 5 LSD) @ 0 to 600A, 40 to 100Hz **
AC Voltage: 400.0 mV 4.000 / 40.00 / 400.0 / 600V Accuracy: +/-(1.5% Rdg + 4 LSD) @ 4V to 400V ranges , 50 to 500 Hz**
DC Voltage: 400.0 mV 4.000 / 40.00 / 400.0 / 600V Accuracy: +/-(0.5% Rdg + 3 LSD) @ 4V to 400V ranges **
Resistance: 400.0 Ohms 4.000 / 40.00 / 400.0 kOhms 4.000 / 40.00 MOhms Accuracy: +/-(0.6% Rdg + 4 LSD) @ 4 to 400 kOhms ranges **
Capacitance: 500.0nF / 5.000 / 50.00 / 500.0 / 3000 uF Accuracy: +/-(3.5% Rdg + 6 LSD)

For complete specs please download the product datasheet under the “Resources” tab.

What’s Included

Description
  • Auto and manual ranging
  • Relative zero mode
  • Auto power off
  • MAX capture function for inrush current measurements (30 mS response)
  • Large, easy to read LCD display

Included Accessories:   Deluxe carrying case, test leads, batteries (installed), users manual

Resources

Data Sheet »
Product Manual »

2 reviews for Amprobe ACDC-100 1000A AC/DC Clamp Meter

  1. ElJefe

    I have used amprobe equipment since the late 60’s

    We bought this unit because one of our other clamp meters had failed. We like it except it doesn’t measure frequency, or have a laser temp probe like the one we were replacing. Our amproble test equipment has proven to be very reliable, we have some that is 25 to 30 years old and still working

  2. mikey

    excellant clamp meter

    This clamp meter excedes my needs it does everything i need +. I use the amp clamp to find shorts in equip wiring, so i need something sturdy and well built, very accurate and this amp meter is all that. I had been using an amprobe model ACDC-610 for about the last 7 yrs and it never failed me once to just recently a fellow co worker knocked it of my tool box and broke it into pieces the hard plastic shattered, i almost cried the meter had never ever been close to dropping off anything and was still in brand new condition. I come to expect the same life of service out of my new meter if not amprobe will be hearing from me lol

    ✔ Yes, I recommend this product.
